| Mobile module | LTE (Cat M1) / NB-IoT / EGPRS |
|---|
| Connector | microUSB |
|---|
| Input voltage range | 5V - powered via microUSB |
|---|
| Power consumption | 3.6 W Max |
|---|
| Status LEDs | 1 x Power LED, 1 x Network LED, 1 x LTE LED |
|---|
| SIM | 1 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V |
|---|
| Power | 1x microUSB |
|---|
| Antennas | 1 x SMA for LTE |
|---|
| Dimensions (W x H x D) | 74.5 x 25 x 64.5 mm |
|---|
| Casing material | Aluminum housing |
|---|
| Weight | 130 g |
|---|
| Mounting options | DIN rail, Flat surface |
|---|
| Operating temperature | -40 °C to 75 °C |
|---|
| Operating humidity | 10% to 90% non-condensing |
|---|
| Ingress Protection Rating | IP30 |
|---|
| Management Software | Windows Connection Manager (NDIS driver) |
|---|
| USB Driver | Windows 7/8/8.1/10, Windows CE 5.0/6.0, Linux 2.6/3.x/4.1~4.14, Android 4.x/5.x/6.x/7.x/8.x |
|---|
| RIL Driver | Android 4.x/5.x/6.x/7.x/8.x |
|---|
| NDIS Driver | Windows 7/8/8.1/10 |
|---|
| Gobinet Driver | Linux 2.6/3.x/4.1~4.14 |
|---|
| Linux Driver | 3.x (3.4 and later)/4.1~4.14 |
|---|
