ASUS Prime Z890M-Plus Wi-FI mATX motherboard

Socket LGA1851, Intel Z890, DDR5

Produktinformation

  • Micro ATX bundkort med socket LGA 1851
  • Intel Z890 chipset
  • Intel® Core™ Ultra Processors (Series 2) support
  • 4 stk. DDR5 RAM sokler, op til 192 GB
  • Dual channel memory support
  • Intel XMP og ASUS AEMP III for enhanced DDR5 performance
  • 1 stk. PCIe 5.0 x16 slot
  • 1 stk. PCIe 4.0 x16 slot (x4 mode)
  • 2 stk. PCIe 4.0 x16 slot (x1 mode)
  • 1 stk. M.2 PCIe 5.0 x4 NVMe SSD slot
  • 2 stk. M.2 PCIe 4.0 x4 NVMe SSD slots
  • 6 stk. SATA 6Gb/s porte
  • Realtek 2.5Gb Ethernet
  • Wi-Fi 7 & Bluetooth 5.4
  • 7.1-Channel High Definition Audio
  • HDMI og DisplayPort port
  • USB Type-C med DisplayPort support
  • USB 3.2 Type A og Type-C porte

2.299,00 kr.

(1.839,20 kr. ekskl. moms)

Konfigurér
10+ tilgængelige
1-3 dages leveringstid
PC & Workstation eksperter
Hjælp & vejledning
Hurtig levering
Kun IT hardware. Intet andet

2.299,00 kr.

(1.839,20 kr. ekskl. moms)

Beskrivelse

ASUS Prime Z890M-Plus Wi-Fi mATX bundkortet er en kompakt og kraftfuld løsning, der er ideel til både gamere og professionelle brugere, der ønsker at bygge en højtydende pc i et mindre kabinet. Med Intel Z890 chipset understøtter dette bundkort de nyeste Intel Core-processorer, hvilket sikrer en kraftfuld og stabil ydeevne til en bred vifte af opgaver. Bundkortet er udstyret med omfattende køleteknologi, herunder VRM-køling og flere fan headers, som sikrer optimal temperaturstyring selv under krævende forhold.

Dette bundkort tilbyder en bred vifte af tilslutningsmuligheder, herunder PCIe 5.0, som giver ekstremt hurtige dataoverførselshastigheder og understøtter de nyeste grafikkort og NVMe SSD'er. Med indbygget Wi-Fi 7 og Bluetooth 5.4 får du den nyeste og mest avancerede trådløse forbindelse, hvilket er ideelt til både arbejde og underholdning. Derudover har bundkortet flere USB-porte, herunder USB 3.2 Gen 2x2 Type-C, som giver hurtig opladning og dataoverførsel til dine eksterne enheder.

ASUS Prime Z890M-Plus Wi-Fi mATX bundkortet er også udstyret med et elegant og funktionelt design, som passer perfekt ind i ethvert mATX-kabinet. Det er nemt at installere takket være det brugervenlige layout og de medfølgende monteringsværktøjer. Dette bundkort er det ideelle valg for brugere, der ønsker at bygge en pålidelig og højtydende pc uden at gå på kompromis med funktioner eller stil.

Hos PROconsult er vi eksperter inden for bygning af computere, og leverer skræddersyede løsninger til både små og store projekter.
Med vores omfattende tekniske ekspertise og erfaring, kan vi producere pålidelige og effektive computere, der opfylder specifikke behov og præferencer.

Produktdetaljer

VarenummerMB-90MB1J80-M0EAY0
MærkeASUS
KategoriIntel 800 Series Chipset
Producent nummer90MB1J80-M0EAY0
Vægt (brutto)2 kg
ModelseriePrime
Form factorMicro ATX
ChipsetIntel Z890
RAM supportDDR5
SocketLGA1851
ModelPRIME Z890M-PLUS WIFI
News & Updates2024/10/24: A new BIOS has been released addressing various bugs, including no display from the graphics card when installing Windows 11 24H2. It is recommended to use the new EZ Flash tool to update directly using the ZIP file downloaded from the ASUS site.
Please visit our GLOBAL website to check and download the latest updates.
CPUSupports Intel® Core™ Ultra Processors(Series 2), LGA1851*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to https://www.asus.com/support/download-center/ for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
ChipsetIntel® Z890 Chipset
Memory4 x DIMM slots, max. 192GB, DDR5
Support up to 8666+MT/s (OC),  Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel® Extreme Memory Profile (XMP)
ASUS Enhanced Memory Profile III(AEMPIII)
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.
** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Graphics1 x DisplayPort**
1 x HDMI™ port***
1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output****
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
**Supports max. 4K@60Hz as specified in DisplayPort 1.4.
***Supports 4K@60Hz as specified in HDMI 2.1.
****Supports max. 4K@120Hz as specified in DisplayPort 1.4.
***** VGA resolution support depends on processors' or graphic cards' resolution.
****** While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.
Expansion SlotsIntel® Core™ Ultra Processors (Series 2)*
1 x PCIe 5.0 x16 slot
Intel® Z890 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
2 x PCIe 4.0 x16 slots (support x1 mode)
* Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).
- To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
StorageTotal supports 3 x M.2 slots and 6 x SATA 6Gb/s ports*
Intel® Core™ Ultra Processors (Series 2)*
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
Intel® Z890 Chipset
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
6 x SATA 6Gb/s ports
* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5.
Ethernet1 x Realtek 2.5Gb Ethernet
ASUS LANGuard
Wireless & BluetoothWi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4***
*Wi-Fi features may vary depending on the operating system
For Windows 11, Wi-Fi 7 will require  24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details.
** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
*** The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
USBRear USB (Total 8 ports)
1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)
1x USB 10Gbps port (1 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A) **
Front USB (Total 7 ports)
1 x USB 5Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports**
* USB Type-C® power delivery output: max. 5V/3A
** USB_E1 port, USB_E2 port, USB_E3 port and USB_E4 port share the bandwidth.
AudioRealtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)
1x USB 10Gbps port (1 x Type-A)
4 x USB 5Gbps ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet
3 x Audio jacks
1 x BIOS FlashBack™ button
Internal I/O ConnectorsFan and cooling related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V CPU Power connector
1 x 4-pin +12V CPU Power connector
Storage related
3 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 5Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin Front Panel System header
1 x Thunderbolt™ (USB4®) header
Special FeaturesASUS 5X PROTECTION III
- DIGI+ VRM (- Digital power design with DrMOS)
- LANGuard
- Overvoltage Protection
- SafeSlot
- Stainless-Steel Back I/O
ASUS Q-Design
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- ProCool
- Pre-mounted I/O shield
Aura Sync
- Aura RGB header
- Addressable Gen 2 headers
Software FeaturesASUS Exclusive Software
Armoury Crate
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
ASUS AI Advisor
ASUS DriverHub
ASUS GlideX
TurboV Core
ASUS CPU-Z
Norton 360 for Deluxe (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
NPU Boost (Intel K-series Processors only)
BIOS256 (128+128) Mb Flash ROM, UEFI AMI BIOS
ManageabilityWOL by PME, PXE
AccessoriesCables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS WiFi Q-Antenna
3 x Screw packages for M.2 SSD
Documentation
1 x Quick start guide
Operating SystemWindows 11  (22H2 & later)
Form FactormATX Form Factor
9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
