| Working Modes | Range Extender/Access Point |
|---|
| Plug Type | EU, UK, US, AU, KR, JP |
|---|
| Standards and Protocols | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|---|
| Interface | 1 x 10/100/1000M Ethernet Port (RJ45) |
|---|
| Ports | 1 Gigabit Ethernet Port |
|---|
| Button | WPS Button, Reset Button, LED Button, Power Button |
|---|
| Input Power | 100-240V~50/60Hz |
|---|
| Power Consumption | 10W（max power consumption） |
|---|
| Dimensions ( W x D x H ) | 6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm) |
|---|
| Antenna | 3 x external |
|---|
| Wireless Standards | IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz |
|---|
| Frequency | 2.4GHz & 5GHz(11ac) |
|---|
| Signal Rate | 5GHz:Up to 1300Mbps |
|---|
| 2.4GHz:Up to 450Mpbs |
|---|
| Reception Sensitivity | 5GHz： |
|---|
| 11a 6Mbps:-93dBm@10% PER |
|---|
| 11a 54Mbps: -76dBm@10% PER |
|---|
| 11ac HT20 mcs8: -68dBm@10% PER |
|---|
| 11ac HT40 mcs9: -64dBm@10% PER |
|---|
| 11ac HT80 mcs9: -61dBm@10% PER |
|---|
| 2.4GHz |
|---|
| 11g 54M: -77dBm@10% PER |
|---|
| 11n HT20 mcs7: -73dBm@10% PER |
|---|
| 11n HT40 mcs7: -70dBm@10% PER |
|---|
| Wireless Modes | Range Extender |
|---|
| Wireless Functions | Wireless Statistic |
|---|
| Concurrent Mode boost both 2.4G/5G WiFi band |
|---|
| High Speed Mode for great speed for HD Gaming and video |
|---|
| Access Control |
|---|
| LED Control |
|---|
| Domain Login Function |
|---|
| Wireless Security | 64/128-bit WEP |
|---|
| WPA-PSK / WPA2-PSK |
|---|
| Transmission Power | <20dBm(2.4GHz) |
|---|
| <23dBm(5GHz) |
|---|
| Certification | CE, FCC, RoHS |
|---|
| Package Contents | AC1750 Wi-Fi Range Extender RE450 |
|---|
| Quick Installation Guide |
|---|
| Box Dimensions (W X D X H) | 7.9 x 4.9 x 3.4in. (202x 125 x 86mm) |
|---|
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
|---|
| Environment | Operating Temperature: 0°C~30°C (32°F~86°F) |
|---|
| Storage Temperature: -40°C~70°C (-40°F~158°F) |
|---|
| Operating Humidity: 10%~90% non-condensing |
|---|
| Storage Humidity: 5%~90% non-condensing |
|---|
