Produktdetaljer
| Varenummer | KAB-BG022 |
|---|---|
| Farve | Sølv (Silver) |
| Mærke | be quiet! |
| Kategori | Midi Tower |
| Producent nummer | BG022 |
| Vægt (brutto) | 8,74 kg |
| Model | Pure Base 600 Silver |
|---|---|
| PSU form factor | ATX PS/2 |
| Motherboard compatibility | ATX / M- ATX / Mini- ITX |
| Case size excl. stands (L x W x H), (mm) | 492 x 220 x 445 |
| Installation of motherboards with backplate | ✓ |
| Case size incl. stands (L x W x H), (mm) | 492 x 220 x 470 |
| Dimensions side panel window (L x W), (mm) | - |
| Color option | Silver |
| Weight (kg) | 7.44 |
| USB 2.0 | - |
| USB 3.2 Gen. 1 | 2 |
| USB 3.2 Gen. 2 Type C | - |
| HD Audio I/O | Mic + Audio |
| Expansion slots | 7 |
| Fan mounting locations | 7 |
| Qi charger / Quick Charging Option | - |
| Top cover | ABS |
| Side panel | Steel |
| Side panel window | - |
| Front panel | ABS |
| Stands | ABS |
| 5.25 bays | 2 |
| 3.5 slots (max.) | 5 |
| 3.5 slots (scope of delivery) | 3 |
| 2.5 slots (max.) | 12 |
| 2.5 slots (scope of delivery) | 8 |
| Fan @ top | - |
| Fan @ front | 1x Pure Wings 2 140mm |
| Fan @ rear | 1x Pure Wings 2 120mm |
| Dimensions (L x W x H), (mm) | Front: 140 x 140 x 25 / Rear: 120 x 120 x 25 |
| Fan speed @ 100% PWM / 12V (rpm) | Front: 900 / Rear: 1200 |
| Noise level @ 100% PWM / 12V ( dB(A) ) | Front: 17.1 / Rear: 16.8 |
| Airflow @ 100% PWM / 12V ( CFM / m3/h ) | Front: 55.8/94.80 / Rear: 41.7/70.84 |
| Air Pressure @ 100% PWM / 12V ( mm H2O ) | Front: 0.6 / Rear: 0.9 |
| Voltage range (V DC) | 5 - 12 |
| Input power (W) | Front: 1.08 / Rear: 1.04 |
| Input current (A) | 0.09 |
| Connector | 3-pin |
| Lifespan (h / 25°C) | 80,000 |
| Fan controller | Manual 3-step fan controller (3x 3-pin) |
| Front (mm) | 1x 120 / 1x 140 |
| Top (mm) | 2x 140 / 3x 120 |
| Bottom (mm) | - |
| Side panel (mm) | - |
| PSU shroud | - |
| Front (mm) | 120 / 140 / 240 / 280 / 360 |
| Top (mm) | 120 / 240 / 360 |
| Bottom (mm) | - |
| Rear (mm) | 120 |
| Max.construction height of CPU cooler unit (mm) | 165 |
| Airflow channel | Front / Top / Rear |
| RGB LED illumination | - |
| LEDs synchronizable with RGB controller/motherboard | - |
| Expandable RGB controller | - |
| Maximum dimensions excl. bottom fan (mm) | 210 |
| Maximum dimensions incl. bottom fan (mm) | 210 |
| HDD cage (in height of graphics card) installed (mm) | 280 |
| HDD cage (in height of graphics card) removed (mm) | 425 |
| Top panel insulation mats | ✓ |
| Front panel insulation mats | ✓ |
| Side panel insulation mats | ✓ |
| Anti-vibration decoupled HDD | ✓ |
| Anti-vibration decoupled fan | - |
| Anti-vibration decoupled PSU | ✓ |
| Anti-vibration decoupled motherboard-tray | - |
| Front | 1 |
| Bottom | 1 |
| Side panel | - |
| Screw set (Drives/Motherboard) | ✓ |
| Rubber rail (pcs.) | - |
| Standoff (pcs.) | - |
| LCS bracket (pcs). | - |
| HDD slot cover (pcs.) | - |
| Upper fan bracket (pcs.) | - |
| HDD panel rubber grommet (pcs.) | - |
| SSD bracket for PSU shroud | - |
| LED strips (pcs.) | - |
| Cable ties (pcs.) | 4 |
| Warranty (Years) | 3 |
| International hotline / free of charge | ✓ / DE, FR |
| Article number | BG022 |
| EAN code | 4260052185421 |
| Certifications | CE / RoHS |
| Dimensions, package (L x W x H), (mm) | 517 x 288 x 568 |
| Gross weight, package (kg) | 8.74 |
| Pieces per packaging unit | 1 |
