Produktdetaljer
| Varenummer | PSU-BN328 |
|---|---|
| Farve | Sort (Black) |
| Mærke | be quiet! |
| Kategori | ATX strømforsyning |
| Producent nummer | BN328 |
| Vægt (brutto) | 1 kg |
| Modelserie | System Power |
| Energi effektivitet | 80 Plus Bronze |
|---|
| Standard | Version 2.5 |
|---|---|
| Strømforsyning effekt | 650 W |
| Model | System Power 10 650W |
|---|---|
| Continuous power (W) | 650 |
| Peak power (W) | - |
| Form factor | Version 2.52 |
| Form factor EPS 12V | Version 2.92 |
| Topology | DC/DC |
| Digitally controlled | - |
| Voltage ( Vac ) | 200 - 240 |
| Frequency ( Hz ) | 50 |
| Input current (A) | 5 |
| Power factor at 100% load | >0.95 |
| Modern standby | ✓ |
| Power consumption in standby (W) | <0.15 |
| Average life time (h / 25°C) | > 100,000 |
| Operating temperature up to (°C) | 40 |
| 80 PLUS certification | Bronze |
| Efficiency (%) at 230V, 2% load | 61.4 |
| Efficiency (%) at 230V, 10% load | 83.8 |
| Efficiency (%) at 230V, 20% load | 88.0 |
| Efficiency (%) at 230V, 50% load | 88.5 |
| Efficiency (%) at 230V, 100% load | 85.6 |
| Fan | temperature-controlled quality fan |
| Fan size (mm) | 120 |
| Bearing technology | Sleeve |
| Motor technology | 4-pole fan motor |
| Max. fan speed (rpm) | 2100 |
| dB(A) at 10% load | 8.8 |
| dB(A) at 20% load | 8.9 |
| dB(A) at 50% load | 11.2 |
| dB(A) at 100% load | 30.7 |
| Multi-rail operation ( 12V rails ) | 1 |
| 12V single rail operation | - |
| Overclocking key | - |
| '+3.3V (A) | 20 |
| '+5V (A) | 20 |
| '+12V1 (A) | 54.17 |
| '+12V2 (A) | - |
| '+12V3 (A) | - |
| '+12V4 (A) | - |
| '+12V5 (A) | - |
| '+12V6 (A) | - |
| -12V (A) | 0.3 |
| '+5Vsb (A) | 3 |
| Max. combined power 12V (W) | 650 |
| Max. combined power 12VHPWR (W) | 0 |
| Max. combined power 3.3V + 5V (W) | 120 |
| Hold-up time at 100% load (ms) | 17 (@75%) |
| Power good signal (ms) | 100 - 150 |
| Modular cables | - |
| Sleeved cables | P24 |
| Flat cables | P4 +4, P4 , PCIe , drives |
| Maximum cable length (cm) | 79 |
| Cable length to motherboard (cm) | 55 |
| No. of cables | 7 |
| ATX -Motherboard ( 20+4-pin ) | 1 |
| P4 +4 (CPU) | 1 |
| P8 (CPU) | - |
| P4 (CPU) | 1 |
| 12VHPWR cables | 0 |
| PCI-e 6+2-pin ( GPU ) | 2 |
| PCI-e 6-pin ( GPU ) | - |
| SATA | 6 |
| PATA | 1 |
| FDD (Floppy) | - |
| OTP (over temperature protection) | ✓ |
| OCP (over current protection) | ✓ |
| OPP (over power protection) | ✓ |
| SCP (short circuit protection) | ✓ |
| OVP (over Voltage protection) | ✓ |
| UVP (under Voltage protection) | ✓ |
| SIP (Surge & Inrush Protection) | ✓ |
| BSMI | - |
| CB | ✓ |
| CCC | - |
| CE | ✓ |
| cRUus | - |
| cTUVus | - |
| CU | ✓ |
| FCC | - |
| RCM | - |
| TÜV | ✓ |
| UKCA | ✓ |
| Energy Star | 6.1 |
| ErP | ✓ |
| WEEE | ✓ |
| RoHS | ✓ |
| Triman | - |
| Thumb screws | - |
| Screws | ✓ |
| Cable ties | - |
| Velcro cable ties | - |
| User manual languages | DE, EN, ES, FR, PL, RU |
| OCK slot bracket with switch / OCK jumper | - |
| SFX -to- ATX adapter bracket | - |
| Dimensions without cable (L x W x H), (mm) | 150 x 140 x 86 |
| Weight (kg) | 1.86 |
| Color | Black |
